Atlas Log-200 Multi-use Temperature Data Logger

Atlas Log-200 Multi-use Temperature Data Logger

Temperature range: -200℃~+90℃(external probe)

Temperature Accuracy: ±0.5℃(-90℃~+70℃)/±1℃(others)

Run Days: Max. 90 days

The Atlas Log-200 Multi-use Temperature Data Logger is a multi-purpose, configurable, battery-replaceable temperature logger with an external probe that monitors temperatures ranging from -30°C to +70°C, -90°C to +200°C and -200°C to +90°C rated temperature ranges.

Introduction

Atlas Log-200 Multi-use Temperature Data Logger with LCD display, you can view temperature data and changes in real time. The logger can store up to 35,000 readings for up to 90 days. Users can use the mobile phone software to directly configure parameters, and an encrypted report will be automatically generated after the trip, and an unmodifiable PDF/CSV report will be generated.

Features

1. The parameters are configurable, and the parameters can be freely configured through the configuration software.

2. With replaceable batteries, its batteries can work for up to 180 days. Batteries can be replaced and reused.

3. Up to 6 alarm points can be set, and up to 9 marks can be made.

4. Password protection, you can set a password to prevent others from operating the device without authorization.

5. High precision, the external probe can measure the temperature from -90℃ to +200℃ with high precision.

6. LCD displays all parameters: normal, alarm, maximum/minimum/average temperature values, operating status, and battery level.

7. Ad hoc reports are available, Ad hoc mode allows the device to continue working after the user generates and reads an ad hoc report. The current data information can be read through the configuration software.

8. Automatically generate PDF/CSV/PDF+CSV reports with charts without additional software.

9. LCD alarm indication, once the temperature exceeds the preset alarm range, the alarm symbol (x) will be displayed on the LCD screen

10. The temperature unit can be switched, Celsius (°C) and Fahrenheit (°F) can be switched freely.

11. Large memory capacity, to the maximum. 35000 readings for PDF report only; maximum. 20,000 readings in PDF and CSV reports.

Specification

Model	Atlas Log-200	Type	Reusable
Run Days	Max. 90 days
Memory Capacity	PDF: Max. 35000 readings; PDF&CSV: Max. 20000 readings
Temperature Range	-200℃~+90℃(external probe)
Temperature Accuracy	±0.5℃(-90℃~+70℃)/±1℃(others)
Alarm Type	LCD screen display, buzzer (about 60dB at 3m)
LCD Screen Display	Normal, Alarm, Max/Min/Average Temperature Value, Running Status
Resolution	0.1℃	Logging Interval	1 minute-24 hours
Start Delay	0 minute-24 hours	Report Format	Automatic PDF/CSV report
Connection	USB, NFC (optional)	Compatible OS	Windows, Mac
Battery	CR2450	Dimensions	96mm44mm15mm
Protection Grade	IP65	Certifications	CE, ROSH, EN12830

Applications

Atlas Log-200 Multi-use Temperature Data Logger is used for ultra-low temperature recording and monitoring in cold storage, cold chain transportation, and dry ice storage environments. It can be used for continuous recording of biopharmaceuticals, life sciences, biological samples, pharmaceutical cold chains, vaccine cold chains, blood cold chains, and diagnostic reagents (including biological reagents, molecular reagents, covid-19 reagents, and cell biology reagents).
